Heavy Duty V Mesh
EuroGuard® Extra | Welded Mesh Panel
EuroGuard® Extra mesh security fencing is unique to Jacksons and features 5mm wires (measured before coating) and smaller mesh apertures formed from a 200 x 30mm mesh pattern. EuroGuard Extra has more wires per panel, which increases rigidity and strength. It is ideal for applications where a stronger fence than standard V mesh fencing is required.
25 year service life guarantee
Installation
We provide nationwide installation for all of our security fencing, gates, and acoustic barriers. Installation is carried out by our experienced gangs who have extensive knowledge of our products and install to our premium standards. Let us know if you require installation when you make an enquiry using our product quote form or by calling us.
EuroGuard® Extra Features
- Posts can be customised for Barbed wire / Razor wire / Rota Spike®/ Alarm-aFence®
- Mesh 200 x 30mm centres with 25mm gap, 5mm wire (wire measured prior coating)
- Anti-climb design
- V mesh design offers strength and security without an intimidating appearance
- Unique vandal-proof panel to post fixings
- 2 - 4 reinforcement folds according to height
- Can be stepped to accommodate sloping ground
- Matching single leaf and double leaf gates available
Panels
Mesh panels with 'V' profile with 2-4 reinforcing folds (subject to height) are made using 5mm horizontal and vertical wires (measured before coating), with 200 x 30mm wire centres, welded at intersections and Galfan zinc alloy treated.
Gates
We manufacture matching single and double leaf gates for this product, with a range of opening actions and manual and automatic operating options.
Browse Gates
EuroGuard® Extra Panel Specifications
| Height (mm) | Post Centres (mm) |
Post Dimensions (mm) |
Overall Post Length (mm) |
| 2010 | 3054 | 80 x 60 | 2800 |
| 2410 | 3054 | 80 x 60 | 3300 |
Post Options
Standard Finishes
Explore our finishes
Standard Colours
Standard powder coating colours:
Document Downloads
Download specification documents, drawings and case studies for this product
Welded Mesh Panel Range
We have a wide range of welded mesh panels, all with a 25 year guarantee. Browse individual products or view the full range below.
View Range
